NGC Makes an Outstanding Appearance at the China International Rubber Technology Exhibition

Published: 2024-09-20



From September 19th to 21st, 2024, the 22nd China International Rubber Technology Exhibition was held at the Shanghai New International Expo Center. The exhibition featured over 800 exhibitors, covering an area of 56,000 square meters. Exhibitors came from nearly 30 countries and regions around the world, representing a variety of industries covering rubber machinery and equipment, rubber chemicals, rubber raw materials, tires, non-tire rubber products, and rubber recycling. It is a popular annual event for operators at all levels of the rubber industry.

NGC is a professional gearbox manufacturing company, and has always been forging ahead since the production of its very first hard-tooth mixer gearbox in 1987, continuously innovating and introducing new products. Since 2022, NGC has been independently developing the MGDS-M series of permanent magnet gear drive systems for mixers. The first 2500kW product has already been running smoothly for 7,000 hours at client site, earning praise and recognition from customers. At this exhibition, NGC showcased its 3MW mixer permanent magnet gear drive system. NGC welcomed all visitors to its booth for further information.

Star Exhibits

3000kW Mixer Permanent Magnet Gear Drive System (MGDS-M650)

NGC's newly developed MGDS-M series mixer permanent magnet-gear drive system incorporates a variety of technologies, including electromechanical system torque fluctuation optimization, NVH control, efficiency enhancement, and topological optimization. This enables it to leverage the high efficiency of permanent magnet motors, high torque density ratio of gear transmission, and intelligent control of frequency conversion systems. The system features high efficiency, high reliability, and a high torque density ratio, satisfying all operating requirements of mixers.

Technical Specifications of the Permanent Magnet Mixer Drive System Series Products
Structure: Electromechanical Integration
Drive Power: 800~3000kW
Voltage Rating: 6kV/10kV
Output Torque: 130~580kNm
Output Speed: 40~60rpm
System Efficiency: ≥94%

MR Series Coaxial Helical Gear Reduction Motor (Helical Gear, Gear Motor)

The MR Series of Helical Gear Reduction Motors is suitable for various industrial applications, offering good adaptability and combinability. These products effectively enhance the performance of various drive solutions, while offering a small footprint, thus achieving an ideal combination of reliability, functionality, and intelligence.

Technical Specifications
Power: 0.09 - 160 kW
Output Speed: 0.05 - 973 rpm
Output Torque: 50 - 18000 Nm
Efficiency: 96% - 99%
Mounting Methods: Flange + Solid Shaft, Foot + Solid Shaft
Single-stage series and two/three-stage coaxial series
High output torque, high allowable radial load

MK Series Helical-Bevel Gear Reduction Motor (Helical-Bevel Gears, Gear Motor)

Thanks to its high-strength gear modules and excellent manufacturing quality, the MK Series of Helical-Bevel Gear Reduction Motors offers an exceptional user experience. The application of modular technology has created a star product with a compact structure and high torque capacity. This series offers a wide range of transmission ratios, various mounting and combination options, and provides a maximum motor power of 200kW. The mechatronic design effectively reduces energy consumption, especially in limited space applications, providing reliable performance and energy efficiency, significantly reducing the maintenance workload, extending service life, and lowering operating costs.

Technical Specifications
Power: 0.12 - 200 kW
Output Speed: 0.1 - 522 rpm
Output Torque: 200 - 50,000 Nm
Efficiency: 90% - 96%
Mounting Methods: Flange + Solid Shaft, Foot + Solid Shaft, Flange + Hollow Shaft, Foot + Hollow Shaft, Torque Arm + Hollow Shaft
Hollow Shaft: Single Key, Involute Spline, Locking Disk

MF Series Parallel Shaft - Helical Gear Reduction Motor (Parallel Shaft - Helical Gear, Gear Motor)

The MF Series of Parallel Shaft - Helical Gear Reduction Motors is designed with a simple and reliable structure. The products offer a wide range of motor power and transmission ratios, with numerous output options. This product series is known for its high efficiency, strong load-bearing capacity, and accurate and reliable transmission. The modular technology provides a variety of combination possibilities, as well as a number of different functions, making it the ideal choice for drive systems for use in various forms of lifting and conveying equipment.

Technical Specifications
Power: 0.12 - 200 kW
Output Speed: 0.1 - 752 rpm
Output Torque: 130 - 18,000 Nm
Efficiency: 96% - 99%
Mounting Methods: Flange + Solid Shaft, Foot + Solid Shaft, Flange + Hollow Shaft, Foot + Hollow Shaft, Torque Arm + Hollow Shaft
Hollow Shaft: Single Key, Involute Spline, Locking Disk

MS Series Helical-Worm Gear Reduction Motors (Helical-Worm Gear, Gear Motor)

The MS Series of Helical-Worm Gear Reduction Motors benefits from excellent quality control and intelligent structural design. This series not only retains the characteristics of large transmission ratio and compact dimensions of the worm gear structure but also features smooth operation, low noise, user-friendliness, high energy efficiency, simple maintenance, low operating costs, and the ability to achieve a large transmission ratio in a small space with good control precision, making it the ideal choice for smart and efficient applications.

Technical Specifications
Two-stage reduction, high reduction ratio, smooth transmission
Power: 0.12 - 22 kW
Output Speed: 0.1 - 397 rpm
Output Torque: 92 – 4,200 Nm
Efficiency: 80% - 95%
Mounting Methods: Flange + Solid Shaft, Foot + Solid Shaft, Flange + Hollow Shaft, Torque Arm + Hollow Shaft
Hollow Shaft: Single Key, Locking Disk
